Product Summary
The STK795-820 is a chopper type voltage regulator.
Parametrics
STK795-820 absolute maximum ratings: (1)DC input voltage, VIN: 40V; (2)Output current, IO: 3A; (3)Operating case temperature, TC: 105℃; (4)Storage temperature, Tstg: -30 to +105℃.
Features
STK795-820 features: (1)Self-oscillation type chopper regulator power IC using Sanyo original IMST substrate; (2)The STK795-820 being a 5V chopper IC, is more advantageous in the following points as compared with series regulator ICs; (3)Functional trimming is used to set 5V output with high accuracy; (4)Cutoff function to cut off output voltage by external signal; (5)Contains a transistor for overcurrent protector and possible to set the protection level externally.
Diagrams
 |
