Product Summary
The CJ1W-MAD42 is a SYSMAC CJ-Series Analog I/O Unit.
Parametrics
CJ1W-MAD42 absolute maximum ratings: (1)Unit type: CJ-series Special I/O Unit; (2)Isolation: Between I/O and PLC signals: Photocoupler; (3)External terminals: 18-point detachable terminal block (M3 screws); (4)Current consumption: 580 mA max. at 5 V DC; (5)Dimensions (mm): 31 × 90 × 65 mm (W × H × D); (6)Weight: 150 g max.; (7)General specifications: Conforms to general specifications for SYSMAC CJ-series Series.
Features
CJ1W-MAD42 features: (1)Input up to eight analog signals with one Unit; (2)Functions include line disconnection detection, averaging, peak value holding, offset/gain adjustment, and scaling; (3)High-speed A/D conversion in 20μs/point with direct conversion function; (4)Output up to eight analog signals with one Unit; (5)Functions include output holding, offset/gain adjustment, and scaling ; (6)High-speed D/A conversion in 20μs/point with direct conversion function; (7)Input up to four analog signals and output up to two analog signals with one Unit; (8)Functions include line disconnection detection, input averaging, scaling, input peak value holding, output holding, ratio conversion, and offset/gain adjustment.
