Product Summary

The PIC16F917-I/P is a 28/40/44-Pin flash-based, 8-bit CMOS microcontroller with LCD driver and nanoWatt technology. It is available in 28/40/44-pin packages.

Parametrics

PIC16F917-I/P absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800mW; (7)Maximum current out of VSS pin: 300mA; (8)Maximum current into VDD pin: 250mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ±20mA.

Features

PIC16F917-I/P features: (1)Power-saving Sleep mode; (2)Wide operating voltage range (2.0V-5.5V); (3)Industrial and Extended temperature range; (4)Power-on Reset (POR); (5)Power-up Timer (PWRT) and Oscillator Start-up Timer (OST); (6)Brown-out Reset (BOR) with software control option; (7)Enhanced Low-Current Watchdog Timer (WDT) with on-chip oscillator (software selectable nominal 268 seconds with full prescaler) with software enable; (8)Multiplexed Master Clear with pull-up/input pin; (9)Programmable code protection.

Diagrams

PIC16F917-I/P blcok diagram
