Product Summary
The 6MBP200KA060 is an IGBT module. The applications of it are High Power Switching, A.C. Motor Controls, D.C. Motor Controls, Uninterruptible Power Supply.
Parametrics
6MBP200KA060 general specifications: (1)Number of Digits: 20; (2)Number of Segments:160; (3)Package / Case:VSO-56; (4)Maximum Clock Frequency:400 KHz; (5)Operating Supply Voltage:8.50V; (6)Maximum Supply Current:0.12 mA; (7)Maximum Power Dissipation:400 mW; (8)Maximum Operating Temperature:+ 180℃; (9)Minimum Operating Temperature:- 80℃.
Features
6MBP200KA060 features: (1)Square RBSOA; (2)Low Saturation Voltage; (3)Less Total Power Dissipation; (4)Improved FWD Characteristic; (5)Minimized Internal Stray Inductance; (6)Overcurrent Limiting Function.
 |
