Product Summary
The CR250DP-6 is a phase control SCR. Powerex silicon controlled rectifiers are designed for phase control applications. These are all-diffused, compression bonded encapsulated devices employing center-fired gate. The applications are: Power suupplies; Battery charges; Motor control; Light dimmers; VAR generatiors.
Parametrics
CR250DP-6 maximum ratings: (1)RMS On state current, IT RMS: 400A; (2)Average on state current, IT: 250A; (3)Peak one-cycle surge ITBM: 5000A; (4)Critical rate-of-rise of on-state current: 100A; (5)I2t one cycle at 60Hz, I2t: 1.0x10 5 A2s; (6)Peak gate power dissipation: 10W; (7)Average gate power dissipation: 3W; (8)Storage Temperature: -40 to 150℃; (9)Operating temperature: -40 to 150℃; (10)Mouting Torque: 230 to 310 In-lb.
Features
CR250DP-6 features: (1)Low on-state voltage; (2)High dl/dt; (3)High dv/dt; (4)Hermetic packaging; (5)Excellent surge and I2t ratings.
Diagrams
 |
