Product Summary

The 9007-05-00 is an Economy SIP Reed Relay. The 9007-05-00 is the industry choice for a wide variety of designs where economy, performance and a compact package are needed. The 9007-05-00 Spartan Series is a general purpose economy version of the 9001 for applications with less stringent requirements. The relay is well suited for applications in Security, Instrumentation and Modems. The specification table allows you to select the appropriate relay for your application.

Parametrics

9007-05-00 absolute maximum ratings: (1)Voltage rating: 5V; (2)Current rating: 500mA; (3)Temperature range: -20℃ to +85℃.

Features

9007-05-00 features: (1)Hermetically sealed contacts for long life; (2)High dielectric strength available, consult factory; (3)High speed switching compared to electromechanical relays; (4)Molded thermoset body on integral lead frame design; (5)Form C available (9081C); (6)Optional Coil Suppression Diode - protects coil drive circuits; (7)UL File # E67117, CSA File # LR 28537.

Diagrams

9007-05-00 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
9007-05-00
9007-05-00
Coto Technology
Reed Relay Spartan SIP Relay
Data Sheet
0-1: $0.59
1-10: $0.56
10-50: $0.53
50-100: $0.49
