Product Summary
The XV-8000CB is an Ultra Miniature Size Gyro Sensor. The application of the XV-8000CB includes Car navigation system.
Parametrics
XV-8000CB absolute maximum ratings: (1)Operating Voltage, VDD: 5.0 V ±0.25 V; (2)Storage Temperature, TSTG: -40℃ to +85℃; (3)Operating Temperature, TOPR: -40℃ to +85℃; (4)Scale factor, So: 25 mV/(°·s-1) Typ; (5)Bias, V0: 50 % VDD; (6)Rate range, I: ±60 deg/s; (7)Frequency response, BW: 10 Hz Typ; (8)Current consumption, Iop: 4 mA Typ.
Features
XV-8000CB features: (1)Ultra Small Package size SMD (5 ×3.2 ×1.3 mm); (2)5.0V operable device (Ratio metric output); (3)High stability using vibration crystal; (4)With output terminal of temperature sensor.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 XV-8000CB :3 50.3000KHZ+/-60DPS |
|
AUTOMOTIVE GYRO SENSOR +/-60DPS |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
XV-8000CB :3 50.3000KHZ+/-60DPS |
|
AUTOMOTIVE GYRO SENSOR +/-60DPS |
Data Sheet |
Negotiable |
|
||||
