Product Summary
The PM30CSJ060 is an Intelligent Power Module. It is isolated base modules designed for power switching applications operating at frequencies to 20kHz. Built-in control circuits provide optimum gate drive and protection for the IGBT and free-wheel diode power devices. The applications of the PM30CSJ060 are Inverters, UPS, Motion/Servo Control, Power Supplies.
Parametrics
PM30CSJ060 absolute maximum ratings: (1)Power Device Junction Temperature:-20℃ to 150℃; (2)Storage Temperature:-40℃ to 125℃; (3)Case Operating Temperature:-20℃ to 100℃; (4)Mounting Torque, M4 Mounting Screws:0.98 to 1.47 N.m; (5)Module Weight (Typical):60 Grams; (6)Supply Voltage Protected by OC and SC (VD = 13.5V to 16.5V, Inverter Part):400 Volts; (7)Isolation Voltage (Main Terminal to Baseplate, AC 1 min.):2500 Vrms.
Features
PM30CSJ060 features: (1)Complete Output Power Circuit; (2)Gate Drive Circuit; (3)Protection Logic: Short Circuit, Over Current, Over Temperature, Under Voltage.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 PM30CSJ060 |
|
MOD IPM 6PAC 600V 30A |
Data Sheet |
Negotiable |
|
||||||
