Product Summary
The LTG500QV-F03 is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching devices. Customer can use the high quality display. This model LTG500QV-F03 is composed of a TFT-LCD Module(TFT-LCD panel, back-light system). The resolution of a 5.0" contains 320 × 240 pixels and can display Analog RGB colors. Also, this model LTG500QV-F03 is only for applications in SEC reliability condition. If this model is adopted as applications requiring severe conditions, abnormal display and malfunction may occur. The applications of the LTG500QV-F03 include Display terminal for AV Units(DVD, VTR) and Portable LCD TV.
Parametrics
LTG500QV-F03 absolute maximum ratings: (1)Storage temperature, TSTG: -25 to 60℃; (2)Operating temperature (Ambient temperature), TOPR: 050℃.
Features
LTG500QV-F03 features: (1)Thin and light weight; (2)High Luminance, high contrast ratio; (3)Analog Interface(Analog RGB Line inversion Mode); (4)Back-light with CCFL.
Diagrams
