Product Summary
The LQ080V3DG01 is a color active matrix transmissive LCD module. The LQ080V3DG01 is composed of a color TFT-LCD planel, driver ICs, control circuits and power supply circuitry and a backlight unit. Graphics and texts can be displayed on a 640×RGB×480 dots panel with 262144 colors by feeding 18 bit data signal, 4 timing signals, +3.3V or +5V DC power supply for TFT-LCD and AC power supply for backlight.
Parametrics
LQ080V3DG01 absolute maximum ratings: (1)Input voltage VI: -0.3 to +6 V; (2)Supply voltage VCC: 0 to +6 V; (3)Storage temperature Tstg: -25 to +70 ℃; (4)Operating temperature(panel surface) Topp: 0 to +70 ℃; (5)Operating temperature(ambient) Topa: 0 to +55 ℃.
Features
LQ080V3DG01 electrical characteristics: (1)Supply voltage VCC: +3.0 to +3.6 V; (2)Current dissipation ICC: 320 to 440mA; (3)Allowed input ripple voltage VRF: 100 mVP-P; (4)Input voltage(low state) VIL: -0.3 to 0.9 V; (5)Input voltage(high state) VIH: 2.3 to 5.5 V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 LQ080V3DG01 |
Sharp Microelectronics |
TFT Displays & Accessories 8.0" 1 x CCFT VGA |
Data Sheet |
Negotiable |
|
||||
 |
LQ080V3DG01F |
Other |
|
Data Sheet |
Negotiable |
|
||||
